Weight load of 3.3lbs per ft²
(based on 24GA steel envelope)

5” polyisocyanurate foam core with density of 2.5bs./cu.ft est.

Effective R-Value 28.5

Flame Spread Rating (tested in accordance with CAN/ULC S102-10) – 10

Smoke Developed Classification (tested in accordance with CAN/ULC S102-10) – 215

Pre painted galvalume top and bottom steel sheets

Wide selection of colour options available

Patented one piece, continuous corner

Foam-to-foam bond panel joints

Pre finished on exterior and interior sides

High rib profile accommodates mechanical lines

STC Rating (tested in accordance with ASTM E90 standard) – 26
